1. Multi section free combination design, standard: 3 groups of hot air, 1 group of UV and 1 group of air-condition. The user can make many options according to the different printing, different ink.
2. Closed cycle pipe line disturbs inside of the container, make sure there are highly active and steady hot air belch to the stock through the beamaperture. Highly coefficient of heat transfer and highly speed drying.
3. Cooling section keep blowing the cold-air blast through the high pressure blower, cooling the stock fleety.
4. Frequency control, teflon convey belt, thermostability, rub resistance, radiation-hardened, insure the working lift of the machine.
5. Equip the pneumatic lifting set, convenience for cleaning and maintain.
6. Automatically tensioning and correcting set, insure placidly carrying and convenience for using.
| Model | JB-800P | JB-1100P | |
| Max. speed | 60m/min | 60m/min | |
| Powder of convey motor | 0.75KW | 0.75KW | |
| Effective solidify width | 800mm | 1100mm | |
| Hot wind group | Max temperature | 150℃ | 150℃ |
| Power of lamp | Wx9Pcsx3Team | Wx9Pcsx3Team | |
| Hot wind circulate fan | 1.1KWx2x3Team | 1.1KWx2x3Team | |
| UVgroup | UV灯功率 | Wx2Pcsx3Choice | Wx2Pcsx3Choice |
| Power of blower | 0.75KWx2 | 0.75KWx2 | |
| Adsorb motor | 0.75KW | 0.75KW | |
| Air-condition cooler※ | Air-condition power | 0.85KWx2 | 0.85KWx2 |
| Fan power | 0.85KW | 0.85KW | |
| Adsorb motor for feed inlet | 0.55KW | 0.55KW | |
| Weight(about) | 2300kg | 2600kg | |
| Overall dimensions | 11100X130X1650mm | 11100X130X1650mm |
